Conventional pre embedded channels

1. Yuanxing conventional pre embedded groove adopts hot-rolled Q345B or above raw materials, which have good ductility and bearing capacity.

2. The groove structure is divided into toothed and non toothed structures, with toothed structures having good anti slip performance and strong load-bearing capacity.

3. There are two types of anchor rods: welding and hot riveting. Welding has the advantages of saving metal materials, high productivity, good operating conditions, and easy mechanization and automation. The welding part has good mechanical properties and sealing. The quality of riveted products is stable, the structure is earthquake resistant, impact resistant, the connection is firm and reliable, and the dynamic performance is good.

Welding process:

The connection method between the channel and the I-beam is welding: the connection method of welding the I-beam onto the channel.

Riveting process:

The connection method between the groove and the anchor rod is riveting: the anchor rod is threaded through the prefabricated hole in the groove and hot riveted to form a connection method.

External groove

External groove is an installation method that uses hand hole bolts to fix the groove.

Its characteristics are:

Installation is selective: it can be installed in positions where there is a need and hand hole bolt, and can be omitted in positions where it is not needed, which can save some grooves and be installed after the tunnel is formed.

Replaceable embedded channel

1. The replaceable pre embedded groove solves the problem of accurate positioning of anchor rods and solves the problem of traditional pre embedded groove damage and rust that cannot be replaced.

2. Not changing the cross-sectional size, installation method, and bearing capacity of the channel, not occupying the effective space of the tunnel, and not taking up the installation time of mechanical and electrical equipment.

Conventional models and specifications of Yuanxing groove (other models can be customized)
